The main features

◆ The electrical appliances and computer software of the whole machine adopt international famous brand, the quality is stable and reliable; Man-machine interface, multi-touch

screen control, computer order management, easy to operate, faster order exchange (999 orders can be pre-deposited).

◆ The wall board and important parts of the whole machine adopt aging treatment and tempering to eliminate the internal stress of metal; All adopt high precision machining center

production, CNC grinding machine grinding processing.

The whole machine shaft and roll are made of high quality steel, grinding, high precision computer dynamic balance correction, hard chrome plating on the surface.

◆ The transmission gear of the whole machine adopts 20CrMnTi alloy steel, carburized and quenched, hardness HRC58 ~ 62; After grinding teeth processing, grade 6 accuracy, to

ensure long-term use of high accuracy of color.

◆ The transmission parts (shaft and tooth connection) of the whole machine are connected with free key (expansion sleeve) to eliminate the connection gap, which is suitable for

long-term high speed operation with large torque.

◆ The whole machine transmission bearing and the important transmission parts all adopt the strengthened self-aligning bearing, which is easy to maintain and has a long service life.

(Three famous brands: "Hawalo")

◆ The lubrication system of the whole machine adopts spray type automatic lubrication and is equipped with automatic balancing device to keep the oil level of each unit.

◆ The whole machine can adjust the preset position, feed paper, print, slotting and die cutting, automatically reset, and the memory of the combination automatically reset.

◆ The working clearance adjustment of the whole machine is quick and convenient by using spanner free adjustment.

◆ The host machine adopts frequency conversion control to start and run more smoothly and save energy.

◆ No ink shortage alarm device, real-time monitoring of the working status of the ink supply system.

◆ Selection: Ceramic anilox roller; Scraper fixing ink system; Stacking machine.
